Samsung New Max 9000BTU White Heating & Cooling Air Conditioner
Samsung New Max 9000BTU White Heating & Cooling Air Conditioner
Features:
- Fast Cooling
- DuraFin™ Plus
- Hidden Display
Cools You Faster
Fast Cooling
Cool a whole room rapidly and effectively. Fast Cooling mode operates with the fastest fan speed, before slowing down. So it cools or heats much faster compared to the normal mode* and reaches the desired temperature in the shortest time. It’s ideal for immediate relief from the heat outside.
Breathe purer air
HD Filter
Make sure that the air you breathe is always clean and fresh. The HD Filter is really effective at capturing dust, airborne contaminants and allergens, such as pollen, mold spores and pet dander. And it’s also washable, so all you need to do is give it a quick rinse in water and then reuse it.
Enjoy a good sleep
Good Sleep
Enjoy a great night’s sleep – every night! Good Sleep mode automatically controls and fine-tunes the temperature to create the ideal conditions for each stage of the sleep cycle. So you gain precious minutes of sleep and feel fully refreshed. And it also uses less energy than normal cooling.
Cools every corner
2-Way Auto Swing
Create a comfortable environment with an even temperature in every corner. The 2-Way Auto Swing function automatically controls the airflow direction, so it’s quickly and evenly distributed across the room. It can expel cool or warm air further and in every direction to ensure maximum comfort.
Long-lasting cooling
DuraFin+
Stay comfortably cool for much longer. The DuraFin+ is made of corrosion-resistant material to protect the condenser from rusting, which helps to maintain the optimal performance of the Heat Exchanger.
Specifications
-
Capacity (Cooling, Btu/hr) 8530 Btu/hr
-
Capacity (Cooling, kW) 2.50 kW
-
EER (Cooling, W/W) 3.01 W/W
-
Net Dimension (Outdoor, WxHxD, mm) 782×540×320 mm
Specifications Detail
Capacity
- Capacity (Cooling, Btu/hr) 8530 Btu/hr
- Capacity (Heating, Btu/hr) 8872 Btu/hr
- Capacity (Cooling, kW) 2.50 kW
- Capacity (Heating, kW) 2.60 kW
Energy Efficiency
- EER (Cooling, W/W) 3.01 W/W
- COP (Heating, W/W) 3.45 W/W
- EER (Cooling, Btu/hW) 10.28 Btu/hW
- COP (Heating, Btu/hW) 11.78 Btu/hW
Noise Level
- Noise Level (Indoor, High/Low, dBA) 36/24.5 dBA
- Noise Level (Outdoor, High/Low, dBA) 50 dBA
Electrical Data
- Power Source(Φ/V/Hz) 1/ 220~240 / 50
- Power Consumption(Cooling, W) 830 W
- Power Consumption(Heating, W) 753 W
- Operating Current(Cooling, A) 3.80 A
- Operating Current(Heating, A) 3.50 A
Physical specification
- Gross Dimension (Indoor, WxHxD, mm )866×271×367 mm
- Gross Dimension (Outdoor, WxHxD, mm) 823×595×358 mm
- Net Dimension (Indoor, WxHxD, mm) 790×275×200 mm
- Net Dimension (Outdoor, WxHxD, mm) 782×540×320 mm
- Gross Weight (Indoor, kg) 11.0 kg
- Gross Weight (Outdoor, kg) 31.5 kg
- Net Weight (Indoor, kg) 9.0 kg
- Net Weight (Outdoor, kg) 29.0 kg
- Loading Quantity (20/40/40Hft without Pipe) 108/224/262
Technical Information
- Piping Length (Max, m) 15 m
- Piping Height (Max, m) 10 m
- SVC Valve (Liquid (ODxL)) φ6
- SVC Valve (Gas (ODxL)) φ9.52
- Moisture Removal (l/hr) 0.80 l/hr
- Air Circulation (Cooling, ㎥/min) 500 ㎥/min
- Refrigerant (Type) R410A
- Low Ambient (Cooling, ℃) 18~43 ℃
- Low Ambient (Heating, ℃) -7~24 ℃
Air Flow
- Air Direction Control (Up/Down) Auto
- Air Direction Control (Left/Right) Manual
- Air Flow Control Step (Cool/Fan) 3 Step
Convenience
- Indoor Temp. Display Yes
- Display On/Off Yes
- 24-Hour Timer Yes
- Auto Restart Yes
Operating Mode
- Auto Mode Yes
- Fast Cool Yes
- Good Sleep Yes
- Dehumidification Yes
- Fan Mode Yes
